| PartNumber | 990000006 |
| Brand | TPO |
| Size | 3.0 |
| Application | DSC |
| Resolution | 320(RGB)×240 , QVGA |
| Composition | LCM |
| Brightness | 250 cd/m² (Typ.) |
| CR | 400:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | Serial RGB |
| Panel Brand | TPO |
| Panel Model | 990000006 |
| Panel Type | LTPS TFT-LCD , LCM |
| Panel Size | 3.0 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 65.31×36.84 mm |
| Outline | 75.31×43.44 mm |
| Surface | Hard coating (3H) |
| Contrast Ratio | 400:1 (Typ.) |
| Display Colors | 16.7M (8-bit), CIE193140% |
| Response Time | 5/11 (Typ.)(Tr/Td) |
| Viewing Angle | 60/60/50/60 (Min.)(CR≥10)(L/R/U/D) |
| Lamp Type | 3S1PWLEDWithout Driver |
| Signal Interface | Serial RGB (8-bit) + SPI, 39 pins |
| Input Voltage | 3.3V (Typ.) |
| 990000006 | TPO | 3.0 | 320×240 |
| 990000270 | TPO | 2.5 | 320×240 |
| 990000475 | TPO | 4.3 | 800×480 |
| 990000475P | TPO | 4.3 | 800×480 |
| 990000553 | TPO | 3.5 | 320×240 |
| 990000738 | TPO | 3.5 | 320×240 |
| 990000738A | Innolux | 3.5 | 320×240 |
| 990000881 | TPO | 3.0 | 960×480(dot) |
| 990001086 | Innolux | 3.0 | |
| A030DN01 V9 | AUO | 3.0 | 320×240 |
| A017CN01 V2 | AUO | 1.7 | 480×240 |
| A018AN03 V1 | AUO | 1.8 | 280×220 |
| A024CN03 V2 | AUO | 2.4 | 480×234 |
| COM30T3N64ZLG | ORTUSTECH | 3.0 | 320×240 |
| DLC0350CZG-T | Other | 3.5 | 320×240 |
| LS020A8DX02 | SHARP | 2.0 | 320×240 |
| LTV350QV-F0E | Samsung | 3.5 | 320×240 |
| TM027CDH12 | Tianma | 2.7 | 320×240 |
| TM030CDH51-00 | Tianma | 3.0 | 320×240 |
| UP018D11 | UNIPAC | 1.8 | 528×220(dot) |
