| PartNumber | A030DN01 VC |
| Brand | AUO |
| Size | 3.0 |
| Application | DSC |
| Resolution | 320(RGB)×240 , QVGA |
| Composition | LCM |
| Brightness | 350 cd/m² (Typ.) |
| CR | 300:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | Serial RGB |
| Panel Brand | AUO |
| Panel Model | A030DN01 VC |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 3.0 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 60×45 mm |
| Outline | 70.2×51.4 mm |
| Surface | Hard coating |
| Contrast Ratio | 300:1 (Typ.) |
| Display Colors | 16.7M (8-bit) |
| Response Time | 10/25 (Typ.)(Tr/Td) |
| Viewing Angle | 60/60/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 3S1PWLEDWithout Driver |
| Signal Interface | Serial RGB (8-bit) + SPI, CCIR601/656, 39 pins |
| Input Voltage | 3.3/15/-10V (Typ.)(VDD/VGH/VGL) |
