| PartNumber | A050FTN01.0 |
| Brand | AUO |
| Size | 5.0 |
| Application | Portable Navigation |
| Resolution | 480×272 |
| Composition | LCM, a-Si TFT-LCD |
| Brightness | |
| CR | 500:1 |
| Colors | 16.7M |
| Backlight | 6S2P WLED , 10K hours , No Driver |
| Interface | |
| Manufacturer | AUO |
| Model Name | A050FTN01.0 |
| Screen Size | 5.0 inch |
| Screen Type | LCM, a-Si TFT-LCD |
| Pixel Number | 480(RGB)×272 (WQVGA) 109PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 110.88 × 62.832 (H×V) |
| Outline(mm) | 120.7 × 75.8 × 3.25 (H×V×D) |
| Bezel Area(mm) | 114.7 × 66.03 (H×V) |
| Treatment | Antiglare, Hard coating (3H) |
| Luminance | 500 cd/m² (Typ.) |
| Contrast Ratio | 500 : 1 (Typ.) (TM) |
| Viewing Angle | 70/70/40/60 (Typ.)(CR≥10) |
| Response | 7/23 (Typ.)(Tr/Td) ms |
| Good View at | - |
| Work Mode | TN, Normally White, Transmissive |
| Color Depth | 16.7M 50% NTSC |
| Mass | 60.0g (Typ.) |
| Used for | Portable Navigation MP3 PMP |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: 0 ~ 70 °C |
