| PartNumber | AA106TA01DDE11 |
| Brand | Mitsubishi |
| Size | 10.6 |
| Application | Industrial Outdoor H |
| Resolution | 1280×768 |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | |
| CR | 1000:1 |
| Colors | 262K/16.7M |
| Backlight | WLED |
| Interface | |
| Model | AA106TA01DDE11 |
| Diagonal Size | 10.6 inch |
| Type | a-Si TFT-LCD, LCM |
| Pixel Format | 1280(RGB)×768 [WXGA] 140PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 231.36(H)×138.816(V) mm |
| Outline Dim. | 250(H)×175(V) ×15.5(D) mm |
| Bezel Area | - |
| Treatment | Antiglare, Hard coating (3H) |
| Luminance | 800 cd/m² (Typ.) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 12/12 (Typ.)(Tr/Td) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Operating Mode | SWV, Normally Black, Transmissive |
| Support Color | 262K/16.7M 50% NTSC |
| Light Source | WLED , 100K hours , With LED Driver |
| Weight | 670g (Typ.) |
| Designed For | Industrial Outdoor High Brightness |
| Frame Rate | 60Hz |
| Touch Panel | PCAP |
| Operating Temperature: -30 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| AA106TA01 | Mitsubishi | 10.6 | 1280×768 |
| LQ106K1LA01C | SHARP | 10.6 | 1280×768 |
| LQ106K1LA02 | SHARP | 10.6 | 1280×768 |
| LQ106K1LA05 | SHARP | 10.6 | 1280×768 |
| LTD106EWNN | TOSHIBA | 10.6 | 1280×768 |
| LTL106AL01-001 | Samsung | 10.6 | 1366×768 |
| LTL106HL01-001 | Samsung | 10.6 | 1920×1080 |
| LTN106W1-L01 | Samsung | 10.6 | 1280×768 |
| LTN106W2-L01 | Samsung | 10.6 | 1280×768 |
