| PartNumber | AA123AF01 |
| Brand | Mitsubishi |
| Size | 12.3 |
| Application | Industrial Outdoor H |
| Resolution | 1920×720 |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | |
| Model | AA123AF01 |
| Diagonal Size | 12.3 inch |
| Type | a-Si TFT-LCD, LCM |
| Pixel Format | 1920(RGB)×720 166PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 292.32(H)×109.62(V) mm |
| Outline Dim. | 305.3(H)×127.9(V) ×15.9(D) mm |
| Bezel Area | 295.3(H)×112.6(V) mm |
| Treatment | Antiglare |
| Luminance | 1000 cd/m² (Typ.) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 30 (Max.)(Tr+Td) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Operating Mode | SFT, Normally Black, Transmissive |
| Support Color | 16.7M 72% NTSC |
| Light Source | WLED [10S4P] , 30K hours , W/O Driver |
| Weight | 460g (Typ.) |
| Designed For | Industrial Outdoor High Brightness Automotive Display |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C |
