| PartNumber | AC070MR11 |
| Brand | Mitsubishi |
| Size | 7.0 |
| Application | Industrial Outdoor High Brightness |
| Resolution | 800(RGB)×480, WVGA, 133PPI |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | 1000 cd/m² (Typ.) |
| CR | 1000:1 |
| Colors | 262K/16.7M |
| Backlight | 2 |
| Interface | LVDS |
| Panel Brand | Mitsubishi |
| Panel Size | 7.0" |
| Display Area | 152.4(W)×91.44(H) mm |
| Outline Size | 169.8(W)×109.7(H) ×9.3(D) mm |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Best View on | Symmetry |
| Display Colors | 262K/16.7M |
| Frequency | 60Hz |
| Panel Weight | 185g (Typ.) |
| Signal Interface | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: -40 ~ 85 °C ; Storage Temp.: -40 ~ 90 °C |
| Panel Model | AC070MR11 |
| Panel Type | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | 154.4(W)×93.44(H) mm |
| Surface | Antiglare, Hard coating (3H) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Display Mode | SWV, Normally Black, Transmissive |
| Response Time | 15/15 (Typ.)(Tr/Td) |
| Lamp Type | 2 strings WLED , 50K hours , Without Driver |
| Touch Screen | Without |
