| PartNumber | AL2002A |
| Brand | Other |
| Size | 2.9 |
| Application | |
| Resolution | 20×2 |
| Composition | OLED |
| Brightness | |
| CR | |
| Colors | Mono(White) |
| Backlight | self |
| Interface | CPU |
| Panel Brand | Amson |
| Panel Model | AL2002A |
| Panel Type | PM-OLED , OLED |
| Panel Size | 2.9 inch |
| Display Format | 20 characters × 2 lines |
| Display Fonts | 5×7 dots + cursor |
| Character Size | 3.22×5.57 mm |
| Character Pitch | 3.70×5.95 mm |
| Active Area | 73.52×11.52 mm |
| Bezel Area | 75.32×13.52 mm |
| Outline | 116×37×9.7 mm |
| Contrast Ratio | |
| Display Colors | Mono(White) |
| Driver IC | Built-in KS0066 |
| Signal Interface | 8-bit parallel, 16 pins |
| Input Voltage | 3.3V (Typ.) |
