| PartNumber | AM-1024768TTMQW-T00H |
| Brand | AMPIRE |
| Size | 10.4 |
| Application | Industrial |
| Resolution | 1024×768 |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | |
| CR | 900:1 |
| Colors | 262K/16.7M |
| Backlight | WLED |
| Interface | LVDS |
| Model | AM-1024768TTMQW-T00H |
| Diagonal Size | 10.4 inch |
| Type | a-Si TFT-LCD, LCM |
| Pixel Format | 1024(RGB)×768 [XGA] 123PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 211.2(H)×158.4(V) mm |
| Outline Dim. | 236(H)×176.9(V) ×7.9(D) mm |
| Bezel Area | 214.8(H)×162.0(V) mm |
| Treatment | Antiglare |
| Luminance | 280 cd/m² (Typ.) |
| Contrast Ratio | 900:1 (Typ.) (TM) |
| View Direction | 6 o'clock |
| Response Time | 16 (Typ.)(Tr+Td) |
| Viewing Angle | 75/75/75/75 (Typ.)(CR≥10) |
| Operating Mode | TN, Normally White, Transmissive |
| Support Color | 262K/16.7M |
| Light Source | WLED [4 strings] , 30K hours , With LED Driver |
| Weight | 290g (Max.) |
| Designed For | Industrial |
| Frame Rate | 60Hz |
| Touch Panel | 4-wire Resistive Touch |
| Interface Type | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| Power Supply | 3.3V (Typ.) |
| Environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
