| PartNumber | AM-1280800W2TZQW-00H |
| Brand | AMPIRE |
| Size | 10.1 |
| Application | Industrial |
| Resolution | 1280×800 |
| Composition | LCM , a-Si TFT-LCD |
| Brightness | |
| CR | 800:1 |
| Colors | 16.7M |
| Backlight | 7S4P WLED , 50K hours , No Driver |
| Interface | LVDS |
| Manufacturer | AMPIRE |
| Screen Size | 10.1 inch |
| Pixel Number | 1280(RGB)×800 (WXGA) 149PPI |
| Active Area(mm) | 216.96 × 135.6 (H×V) |
| Bezel Area(mm) | - |
| Luminance | 1000 cd/m² (Typ.) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Good View at | Symmetry |
| Color Depth | 16.7M 44% NTSC |
| Mass | 160g (Max.) |
| Refresh Rate | 60Hz |
| Signal Type | LVDS (1 ch, 8-bit) , 40 pins Connector |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| Model Name | AM-1280800W2TZQW-00H |
| Screen Type | LCM , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Outline(mm) | 231 × 154.4 × 7.9 (H×V×D) |
| Treatment | Glare (Haze 0%), Hard coating (3H) |
| Contrast Ratio | 800 : 1 (Typ.) (TM) |
| Response | 25 (Typ.)(Tr+Td) ms |
| Work Mode | ADS, Normally Black, Transmissive |
| Used for | Industrial |
| Touchscreen | Without |
