| PartNumber | AM-19201200B1TZQW-00-B |
| Brand | AMPIRE |
| Size | 10.1 |
| Application | Industrial Outdoor H |
| Resolution | 1920×1200 |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | |
| CR | 800:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | LVDS |
| Diagonal Size | 10.1 inch |
| Pixel Format | 1920(RGB)×1200 [WUXGA] 224PPI |
| Active Area | 216.806(H)×135.504(V) mm |
| Bezel Area | - |
| Luminance | 1000 cd/m² (Typ.) |
| View Direction | Symmetry |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Support Color | 16.7M 53% NTSC |
| Weight | - |
| Frame Rate | 60Hz |
| Interface Type | LVDS (2 ch, 8-bit) , 40 pins Connector |
| Power Supply | 3.3V (Typ.) |
| Environment | Operating Temperature: -20 ~ 65 °C ; Storage Temperature: -30 ~ 80 °C |
| Model | AM-19201200B1TZQW-00-B |
| Type | a-Si TFT-LCD , LCM |
| Configuration | RGB Vertical Stripe |
| Outline Dim. | 243.45(H)×155.2(V) ×9.61(D) mm |
| Treatment | Antiglare |
| Contrast Ratio | 800:1 (Typ.) (TM) |
| Response Time | 25 (Typ.)(Tr+Td) |
| Operating Mode | Normally Black, Transmissive |
| Light Source | WLED , 50K hours , With LED Driver |
| Designed For | Industrial Outdoor High Brightness |
| Touch Panel | Without |
| AM-19201200B1TZQW-T00 | AMPIRE | 10.1 | 1920×1200 |
| B101EAN01.2 | AUO | 10.1 | 1280×800 |
| B101EAN02.2 | AUO | 10.1 | 800×1280 |
| B101UAN01.9 | AUO | 10.1 | 1920×1200 |
| HSD100IFW4-A00 | HannStar | 10.1 | 1024×600 |
| HSD101PWW1-B00 | HannStar | 10.1 | 1280×800 |
| LP101WH4-SLP2 | LG Display | 10.1 | 1366×768 |
| LTN101NT02-W05 | Samsung | 10.1 | 1024×600 |
| N101ICE-G63 | Innolux | 10.1 | 1280×800 |
| VVX10F011B00 | Panasonic | 10.1 | 1920×1200 |
