| PartNumber | AM-19201200B2TZQW-T06 |
| Brand | AMPIRE |
| Size | 10.1 |
| Application | Industrial |
| Resolution | 1920×1200 |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | |
| CR | 800:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | |
| Diagonal Size | 10.1 inch |
| Pixel Format | 1920(RGB)×1200 [WUXGA] 224PPI |
| Active Area | 216.806(H)×135.504(V) mm |
| Luminance | 340 cd/m² (Typ.) |
| View Direction | Symmetry |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Support Color | 16.7M 53% NTSC |
| Weight | - |
| Frame Rate | 60Hz |
| Model | AM-19201200B2TZQW-T06 |
| Type | a-Si TFT-LCD , LCM |
| Configuration | RGB Vertical Stripe |
| Outline Dim. | 230.12(H)×150.2(V) ×8.26(D) mm |
| Contrast Ratio | 800:1 (Typ.) (TM) |
| Response Time | 25 (Typ.)(Tr+Td) |
| Operating Mode | AHVA, Normally Black, Transmissive |
| Light Source | WLED , 12K hours , With LED Driver |
| Designed For | Industrial |
| Touch Panel | PCAP |
