| PartNumber | AM-19201200CTZQW-T01 |
| Brand | AMPIRE |
| Size | 10.1 |
| Application | Industrial Outdoor H |
| Resolution | 1920×1200 |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | |
| CR | 800:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | |
| Model | AM-19201200CTZQW-T01 |
| Diagonal Size | 10.1 inch |
| Type | a-Si TFT-LCD, LCM |
| Pixel Format | 1920(RGB)×1200 [WUXGA] 225PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 216.576(H)×135.36(V) mm |
| Outline Dim. | 244.8(H)×155.3(V) ×8.01(D) mm |
| Luminance | 850 cd/m² (Typ.) |
| Contrast Ratio | 800:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 25 (Typ.)(Tr+Td) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Operating Mode | AHVA, Normally Black, Transmissive |
| Support Color | 16.7M 49% NTSC |
| Light Source | WLED [7S6P] , 50K hours , W/O Driver |
| Weight | - |
| Designed For | Industrial Outdoor High Brightness |
| Frame Rate | 60Hz |
| Touch Panel | PCAP |
| Operating Temperature: -20 ~ 65 °C ; Storage Temperature: -20 ~ 65 °C |
