| PartNumber | AM-320240N1TMQW-TW0H-A(R) |
| Brand | AMPIRE |
| Size | 5.7 |
| Application | Industrial |
| Resolution | 320×240 |
| Composition | LCM, a-Si TFT-LCD |
| Brightness | |
| CR | 350:1 |
| Colors | 65K/262K |
| Backlight | 3S7P WLED , No Driver |
| Interface | |
| Manufacturer | AMPIRE |
| Model Name | AM-320240N1TMQW-TW0H-A(R) |
| Screen Size | 5.7 inch |
| Screen Type | LCM, a-Si TFT-LCD |
| Pixel Number | 320(RGB)×240 (QVGA) 70PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 115.2 × 86.4 (H×V) |
| Outline(mm) | 167 × 109 × 14.8 (H×V×D) |
| Bezel Area(mm) | 118.2 × 89.4 (H×V) |
| Treatment | - |
| Luminance | 400 cd/m² (Typ.) |
| Contrast Ratio | 350 : 1 (Min.) (TM) |
| Viewing Angle | 70/70/50/70 (Typ.)(CR≥10) |
| Response | 15/35 (Typ.)(Tr/Td) ms |
| Good View at | 6 o'clock |
| Work Mode | TN, Normally White, Transmissive |
| Color Depth | 65K/262K 61% NTSC |
| Mass | TBD |
| Used for | Industrial |
| Refresh Rate | 60Hz |
| Touchscreen | 4-wire Resistive Touch |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
