| PartNumber | AM-480272METMQW-00H |
| Brand | AMPIRE |
| Size | 4.3 |
| Application | Industrial |
| Resolution | 480×272 |
| Composition | LCM, a-Si TFT-LCD |
| Brightness | |
| CR | 500:1 |
| Colors | 16.7M |
| Backlight | 6S2P WLED , 25K hours , No Driver |
| Interface | Parallel |
| Manufacturer | AMPIRE |
| Model Name | AM-480272METMQW-00H |
| Screen Size | 4.3 inch |
| Screen Type | LCM, a-Si TFT-LCD |
| Pixel Number | 480(RGB)×272 (WQVGA) 128PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 95.04 × 53.856 (H×V) |
| Outline(mm) | 105.5 × 67.2 (H×V×D) |
| Bezel Area(mm) | 99.0 × 56.86 (H×V) |
| Treatment | Antiglare, Hard coating (3H) |
| Luminance | 500 cd/m² (Typ.) |
| Contrast Ratio | 500 : 1 (Typ.) (TM) |
| Viewing Angle | 70/70/50/70 (Typ.)(CR≥10) |
| Response | 8/17 (Typ.)(Tr/Td) ms |
| Good View at | 12 o'clock |
| Work Mode | TN, Normally White, Transmissive |
| Color Depth | 16.7M |
| Mass | - |
| Used for | Industrial |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | Parallel RGB (1 ch, 8-bit) , FPC 40 pins |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
