| PartNumber | AM-640480V2TZQW-TA7H |
| Brand | AMPIRE |
| Size | 5.7 |
| Application | Industrial Outdoor High Brightness |
| Resolution | 640(RGB)×480, VGA, 141PPI |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | 850 cd/m² (Typ.) |
| CR | 1200:1 |
| Colors | 262K |
| Backlight | 4S7P |
| Interface | LVDS |
| Panel Brand | AMPIRE |
| Panel Model | AM-640480V2TZQW-TA7H |
| Panel Size | 5.7" |
| Panel Type | a-Si TFT-LCD, LCM |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 115.2(W)×86.4(H) mm |
| Bezel Opening | - |
| Outline Size | 127(W)×98.43(H) ×10.88(D) mm |
| Surface | - |
| Contrast Ratio | 1200:1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Display Mode | IPS, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 30 (Typ.)(Tr+Td) |
| Display Colors | 262K 60% NTSC |
| Lamp Type | 4S7P WLED , 50K hours , With LED Driver |
| Frequency | 60Hz |
| Touch Screen | PCAP |
| Panel Weight | - |
| Signal Interface | LVDS (1 ch, 6-bit) , 20 pins Connector |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
