| PartNumber | AM-800480AZTMQW-05H |
| Brand | AMPIRE |
| Size | 5.0 |
| Application | Industrial |
| Resolution | 800×480 |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | |
| CR | 600:1 |
| Colors | 262K |
| Backlight | WLED |
| Interface | |
| Model | AM-800480AZTMQW-05H |
| Diagonal Size | 5.0 inch |
| Type | a-Si TFT-LCD, LCM |
| Pixel Format | 800(RGB)×480 [WVGA] 188PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 108(H)×64.8(V) mm |
| Outline Dim. | 118.5(H)×77.1(V) ×7.41(D) mm |
| Bezel Area | 110.6(H)×67.4(V) mm |
| Treatment | - |
| Luminance | 500 cd/m² (Typ.) |
| Contrast Ratio | 600:1 (Typ.) (TM) |
| View Direction | - |
| Response Time | 2/6 (Typ.)(Tr/Td) |
| Viewing Angle | 75/75/70/60 (Typ.)(CR≥10) |
| Operating Mode | TN, Normally White, Transmissive |
| Support Color | 262K 47% NTSC |
| Light Source | WLED [3S7P] , 30K hours , With LED Driver |
| Weight | - |
| Designed For | Industrial |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
