| PartNumber | AM-800480AZTMQW-50H |
| Brand | AMPIRE |
| Size | 5.0 |
| Application | Industrial |
| Resolution | 800(RGB)×480, WVGA, 188PPI |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | 1000 cd/m² (Typ.) |
| CR | 600:1 |
| Colors | 16.7M |
| Backlight | 3S6P |
| Interface | |
| Panel Brand | AMPIRE |
| Panel Size | 5.0" |
| Display Area | 108(W)×64.8(H) mm |
| Outline Size | 119.7(W)×78(H) ×6.1(D) mm |
| Viewing Angle | 75/75/70/60 (Typ.)(CR≥10) |
| Best View on | - |
| Display Colors | 16.7M 47% NTSC |
| Frequency | 60Hz |
| Weight | - |
| Panel Model | AM-800480AZTMQW-50H |
| Panel Type | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | - |
| Surface | Antiglare |
| Contrast Ratio | 600:1 (Typ.) (TM) |
| Display Mode | TN, Normally White, Transmissive |
| Response Time | 2/6 (Typ.)(Tr/Td) |
| Lamp Type | 3S6P WLED , 50K hours , Without Driver |
| Touch Screen | Without |
