| PartNumber | AM-800480D1TMQW-00H |
| Brand | AMPIRE |
| Size | 8.0 |
| Application | Industrial Automotiv |
| Resolution | 800×480 |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | |
| CR | 500:1 |
| Colors | 262K/16.7M |
| Backlight | WLED |
| Interface | |
| Model | AM-800480D1TMQW-00H |
| Diagonal Size | 8.0 inch |
| Type | a-Si TFT-LCD, LCM |
| Pixel Format | 800(RGB)×480 [WVGA] 116PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 176.64(H)×99.36(V) mm |
| Outline Dim. | 192.8(H)×116.9(V) ×6.7(D) mm |
| Bezel Area | 180.1(H)×103.4(V) mm |
| Treatment | Antiglare |
| Luminance | 450 cd/m² (Typ.) |
| Contrast Ratio | 500:1 (Typ.) (TM) |
| View Direction | - |
| Response Time | 10/15 (Typ.)(Tr/Td) |
| Viewing Angle | 70/70/50/70 (Typ.)(CR≥10) |
| Operating Mode | TN, Normally White, Transmissive |
| Support Color | 262K/16.7M |
| Light Source | WLED , 20K hours , W/O Driver |
| Weight | 251g (Typ.) |
| Designed For | Industrial Automotive Display |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -30 ~ 85 °C |
