| PartNumber | AM-800480LTMQW-WAH |
| Brand | AMPIRE |
| Size | 5.0 |
| Application | Industrial |
| Resolution | 800×480 |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | |
| CR | 500:1 |
| Colors | 262K |
| Backlight | WLED |
| Interface | CPU |
| Model | AM-800480LTMQW-WAH |
| Diagonal Size | 5.0 inch |
| Type | a-Si TFT-LCD, LCM |
| Pixel Format | 800(RGB)×480 [WVGA] 188PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 108(H)×64.8(V) mm |
| Outline Dim. | 118.5(H)×77.1(V) ×6.37(D) mm |
| Bezel Area | 110.6(H)×67.4(V) mm |
| Treatment | - |
| Luminance | 470 cd/m² (Typ.) |
| Contrast Ratio | 500:1 (Typ.) (TM) |
| View Direction | - |
| Response Time | 15/35 (Typ.)(Tr/Td) |
| Viewing Angle | 70/70/70/50 (Typ.)(CR≥10) |
| Operating Mode | TN, Normally White, Transmissive |
| Support Color | 262K 52% NTSC |
| Light Source | WLED [3S6P] , With LED Driver |
| Weight | TBD |
| Designed For | Industrial |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Interface Type | CPU , 40 pins Connector |
| Power Supply | 3.3V (Typ.) |
| Environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
