| PartNumber | AM-800480N3TZQW-57H |
| Brand | AMPIRE |
| Size | 5.0 |
| Application | Industrial Automotiv |
| Resolution | 800×480 |
| Composition | LCM, a-Si TFT-LCD |
| Brightness | |
| CR | 1000:1 |
| Colors | 262K |
| Backlight | 3S6P WLED , 50K hours , With LED Driver |
| Interface | |
| Manufacturer | AMPIRE |
| Model Name | AM-800480N3TZQW-57H |
| Screen Size | 5.0 inch |
| Screen Type | LCM, a-Si TFT-LCD |
| Pixel Number | 800(RGB)×480 (WVGA) 188PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 108 × 64.8 (H×V) |
| Outline(mm) | 119.7 × 78.3 × 10.05 (H×V×D) |
| Bezel Area(mm) | 109.6 × 66.4 (H×V) |
| Treatment | - |
| Luminance | 1000 cd/m² (Typ.) |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Response | 30 (Typ.)(Tr+Td) ms |
| Good View at | Symmetry |
| Work Mode | IPS, Normally Black, Transmissive |
| Color Depth | 262K |
| Mass | - |
| Used for | Industrial Automotive Display |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Storage Temp.: -30 ~ 85 °C Operating Temp.: -30 ~ 85 °C |
