| PartNumber | AM-800480R2TMQW-U0H |
| Brand | AMPIRE |
| Size | 7.0 |
| Application | Industrial |
| Resolution | 800×480 |
| Composition | LCM , a-Si TFT-LCD |
| Brightness | |
| CR | 250:1 |
| Colors | 65K |
| Backlight | WLED , With LED Driver |
| Interface | UART |
| Manufacturer | AMPIRE |
| Model Name | AM-800480R2TMQW-U0H |
| Screen Size | 7.0 inch |
| Screen Type | LCM , a-Si TFT-LCD |
| Pixel Number | 800(RGB)×480 (WVGA) 133PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 152.4 × 91.44 (H×V) |
| Outline(mm) | 178.5 × 110 × 20.4 (H×V×D) |
| Bezel Area(mm) | 155.3 × 94.3 (H×V) |
| Treatment | - |
| Luminance | 400 cd/m² (Typ.) |
| Contrast Ratio | 250 : 1 (Typ.) (TM) |
| Viewing Angle | 70/70/60/60 (Typ.)(CR≥10) |
| Response | 50 (Typ.)(Tr+Td) ms |
| Good View at | - |
| Work Mode | TN, Normally White, Transmissive |
| Color Depth | 65K 48% NTSC |
| Mass | - |
| Used for | Industrial |
| Refresh Rate | - |
| Touchscreen | Without |
| Signal Type | UART , 8 pins Connector |
| Voltage Supply | 4.6/26.0V (Min./Typ.) |
| Max. Ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
