| PartNumber | AM-800600MGTMQW-02H |
| Brand | AMPIRE |
| Size | 8.4 |
| Application | Industrial |
| Resolution | 800(RGB)×600, SVGA, 119PPI |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | 350 cd/m² (Typ.) |
| CR | 600:1 |
| Colors | 16.7M |
| Backlight | 12S4P |
| Interface | LVDS |
| Panel Brand | AMPIRE |
| Panel Model | AM-800600MGTMQW-02H |
| Panel Size | 8.4" |
| Panel Type | a-Si TFT-LCD, LCM |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 170.4(W)×127.8(H) mm |
| Bezel Opening | 174.15(W)×131.2(H) mm |
| Outline Size | 203(W)×145.5(H) ×11.7(D) mm |
| Surface | - |
| Contrast Ratio | 600:1 (Typ.) (TM) |
| Viewing Angle | 75/75/60/70 (Typ.)(CR≥10) |
| Display Mode | TN, Normally White, Transmissive |
| Best View on | - |
| Response Time | 8 (Typ.)(Tr+Td) |
| Display Colors | 16.7M |
| Lamp Type | 12S4P WLED , 50K hours , With LED Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Panel Weight | TBD |
| Signal Interface | LVDS (1 ch, 8-bit) , 20 pins Connector |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
