| PartNumber | AM-800600MTMQW-50H |
| Brand | AMPIRE |
| Size | 8.4 |
| Application | Industrial Outdoor High Brightness |
| Resolution | 800(RGB)×600, SVGA, 119PPI |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | 1000 cd/m² (Typ.) |
| CR | 600:1 |
| Colors | 262K/16.7M |
| Backlight | 6S5P |
| Interface | |
| Panel Brand | AMPIRE |
| Panel Size | 8.4" |
| Display Area | 170.4(W)×127.8(H) mm |
| Outline Size | 189.75(W)×149.4(H) ×5.3(D) mm |
| Viewing Angle | 75/75/60/70 (Typ.)(CR≥10) |
| Best View on | - |
| Display Colors | 262K/16.7M |
| Frequency | 60Hz |
| Weight | TBD |
| Panel Model | AM-800600MTMQW-50H |
| Panel Type | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | 173.4(W)×130.8(H) mm |
| Surface | - |
| Contrast Ratio | 600:1 (Typ.) (TM) |
| Display Mode | TN, Normally White, Transmissive |
| Response Time | 8 (Typ.)(Tr+Td) |
| Lamp Type | 6S5P WLED , Without Driver |
| Touch Screen | Without |
| AA084SA01 | Mitsubishi | 8.4 | 800×600 |
| AM-800600M3TNQW-00H | AMPIRE | 8.4 | 800×600 |
| AM-800600M3TNQW-01H-F | AMPIRE | 8.4 | 800×600 |
| G084SN05 V3 | AUO | 8.4 | 800×600 |
| G084SN05 V7 | AUO | 8.4 | 800×600 |
| LQ084S3LG03 | SHARP | 8.4 | 800×600 |
| LTA084C190F | TOSHIBA | 8.4 | 800×600 |
| LTA084C274F | TOSHIBA | 8.4 | 800×600 |
| NL6448BC26-08D | NLT | 8.4 | 640×480 |
| NL6448BC26-09C | NLT | 8.4 | 640×480 |
