| PartNumber | AM480272H3TMQW-TW1H |
| Brand | AMPIRE |
| Size | 4.3 |
| Application | Industrial |
| Resolution | 480×272 |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | |
| CR | 250:1 |
| Colors | 65K/262K |
| Backlight | WLED |
| Interface | 8/9/16/18-bit |
| Model | AM480272H3TMQW-TW1H |
| Diagonal Size | 4.3 inch |
| Type | a-Si TFT-LCD, LCM |
| Pixel Format | 480(RGB)×272 [WQVGA] 128PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 95.04(H)×53.856(V) mm |
| Outline Dim. | 105.5(H)×67.2(V) ×7.91(D) mm |
| Luminance | 400 cd/m² (Typ.) |
| Contrast Ratio | 250:1 (Typ.) (TM) |
| View Direction | 6 o'clock |
| Response Time | 15/35 (Typ.)(Tr/Td) |
| Viewing Angle | 70/70/35/55 (Typ.)(CR≥10) |
| Operating Mode | TN, Normally White, Transmissive |
| Support Color | 65K/262K 52% NTSC |
| Light Source | WLED [7S1P] , 15K hours , W/O Driver |
| Weight | TBD |
| Designed For | Industrial |
| Frame Rate | 60Hz |
| Touch Panel | 4-wire Resistive Touch |
| Interface Type | 8/9/16/18-bit 6800/8080 parallel , 40 pins Connector |
| Power Supply | 3.3V (Typ.) |
| Environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
