| PartNumber | AMS596DU08-0 |
| Brand | SAMSUNG |
| Size | 6.0 |
| Application | Mobile Phone |
| Resolution | 1440×2560 |
| Composition | AM-OLED, Assembly |
| Brightness | |
| CR | 10000:1 |
| Colors | 16.7M |
| Backlight | self |
| Interface | MIPI |
| Model | AMS596DU08-0 |
| Diagonal Size | 6.0 inch |
| Type | AM-OLED, Assembly |
| Pixel Format | 1440(RG/BG)×2560 [Quad-HD] 402PPI |
| Configuration | RG/BG PenTile |
| Active Area | 74.16(H)×131.84(V) mm |
| Outline Dim. | 81.26(H)×151.4(V) mm |
| Luminance | 350 cd/m² (Typ.) |
| Contrast Ratio | 10000:1 (Min.) (TM) |
| View Direction | Symmetry |
| Response Time | - |
| Viewing Angle | 88/88/88/88 (Min.)(CR≥10) |
| Operating Mode | - |
| Support Color | 16.7M 100% NTSC |
| Light Source | self |
| Weight | - |
| Designed For | Mobile Phone |
| Frame Rate | 60Hz |
| Touch Panel | PCAP |
| Interface Type | MIPI (2 ch, 4 data lanes) , 60 pins Connector |
| Power Supply | 1.8/3.1/4.0V (Typ.)(IOVDD/VCI/VBAT) |
| Environment | Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
