| PartNumber | AT043TN14 V.1 |
| Brand | Innolux |
| Size | 4.3 |
| Application | Portable Navigation |
| Resolution | 480×272 |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | |
| CR | 500:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | Parallel |
| Model | AT043TN14 V.1 |
| Diagonal Size | 4.3 inch |
| Type | a-Si TFT-LCD, LCM |
| Pixel Format | 480(RGB)×272 [WQVGA] 128PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 95.04(H)×53.856(V) mm |
| Outline Dim. | - |
| Bezel Area | - |
| Treatment | Antiglare |
| Luminance | - |
| Contrast Ratio | 500:1 (Typ.) (TM) |
| View Direction | 6 o'clock |
| Response Time | 10/15 (Typ.)(Tr/Td) |
| Viewing Angle | 70/70/50/70 (Typ.)(CR≥10) |
| Operating Mode | TN, Normally White, Transmissive |
| Support Color | 16.7M |
| Light Source | WLED |
| Weight | - |
| Designed For | Portable Navigation MP3 PMP |
| Frame Rate | - |
| Touch Panel | 4-wire Resistive Touch |
| Interface Type | Parallel RGB (1 ch, 8-bit) , 40 pins FPC |
| Power Supply | (2.5/3.3)/5.0V (Typ.)(VDD/AVDD) |
| Environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
