| PartNumber | AT070WSM-NW2 |
| Brand | BOE |
| Size | 7.0 |
| Application | Automotive Display |
| Resolution | 1024×600 |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | |
| CR | 800:1 |
| Colors | 262K/16.7M |
| Backlight | WLED |
| Interface | |
| Model | AT070WSM-NW2 |
| Diagonal Size | 7.0 inch |
| Type | a-Si TFT-LCD, LCM |
| Pixel Format | 1024(RGB)×600 [WSVGA] 170PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 154.214(H)×85.92(V) mm |
| Outline Dim. | - |
| Luminance | - |
| Contrast Ratio | 800:1 (Typ.) (TM) |
| View Direction | - |
| Response Time | 25 (Typ.)(Tr+Tf) |
| Viewing Angle | 80/80/60/70 (Typ.)(CR≥10) |
| Operating Mode | TN, Normally White, Transmissive |
| Support Color | 262K/16.7M 50% NTSC |
| Light Source | WLED |
| Weight | - |
| Designed For | Automotive Display |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| AT070TN92 V.X | Innolux | 7.0 | 800×480 |
| B070ATN01.0 | AUO | 7.0 | 1024×600 |
| BP070HD1-100 | BOE | 7.0 | 720×1280 |
| C070FW03 V0 | AUO | 7.0 | 480×234 |
| C070VW03 V0 | AUO | 7.0 | 800×480 |
| CLAA070LC0ACW | CPT | 7.0 | 800×480 |
| CLAA070LC0CCW | CPT | 7.0 | 800×480 |
| LB070WQ6-TD01 | LG Display | 7.0 | 400×234 |
| LD070WS2-SL07 | LG Display | 7.0 | 1024×600 |
| ZJ070NA-01P | Innolux | 7.0 | 1024×600 |
