| PartNumber | AV080WSM-NW2 |
| Brand | BOE |
| Size | 8.0 |
| Application | Automotive Display |
| Resolution | 1024×600 |
| Composition | LCM, a-Si TFT-LCD |
| Brightness | |
| CR | 800:1 |
| Colors | 262K/16.7M |
| Backlight | 3S10P WLED , 30K hours , No Driver |
| Interface | LVDS |
| Manufacturer | BOE |
| Model Name | AV080WSM-NW2 |
| Screen Size | 8.0 inch |
| Screen Type | LCM, a-Si TFT-LCD |
| Pixel Number | 1024(RGB)×600 (WSVGA) 148PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 176.64 × 99.36 (H×V) |
| Outline(mm) | 192.8 × 116.9 × 4.7 (H×V×D) |
| Bezel Area(mm) | 180.1 × 103.4 (H×V) |
| Treatment | - |
| Luminance | 600 cd/m² (Typ.) |
| Contrast Ratio | 800 : 1 (Typ.) (TM) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
| Response | 25 (Typ.)(Tr+Td) ms |
| Good View at | Symmetry |
| Work Mode | ADS, Normally Black, Transmissive |
| Color Depth | 262K/16.7M 50% NTSC |
| Mass | 176/180g (Typ./Max.) |
| Used for | Automotive Display |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | LVDS (1 ch, 6/8-bit) , FPC 40 pins |
| Voltage Supply | 3.3/11.5/21/-10V (Typ.)(VDD/AVDD/VGH/VGL) |
| Max. Ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
