| PartNumber | B080EAK02.2 |
| Brand | AUO |
| Size | 8.0 |
| Application | Pad & Tablet |
| Resolution | 800(RGB)×1280, WXGA, 188PPI |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | 360 cd/m² (Typ.) |
| CR | 900:1 |
| Colors | 16.7M |
| Backlight | 4S5P |
| Interface | MIPI |
| Panel Brand | AUO |
| Panel Model | B080EAK02.2 |
| Panel Size | 8.0" |
| Panel Type | a-Si TFT-LCD, LCM |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 107.64(W)×172.224(H) mm |
| Bezel Opening | - |
| Outline Size | 113.72(W)×183.764(H) ×4.1(D) mm |
| Surface | Glare (Haze 0%) |
| Contrast Ratio | 900:1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Display Mode | AHVA, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 25 (Typ.)(Tr+Tf) |
| Display Colors | 16.7M 58% NTSC |
| Lamp Type | 4S5P WLED , 15K hours , Without Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Panel Weight | 120g (Max.) |
| Signal Interface | MIPI (4 data lanes) , 39 pins Connector |
| Input Voltage | 1.8/3.3V (Typ.)(VCC1/VC2) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
