| PartNumber | B116XAT03.1 |
| Brand | AUO |
| Size | 11.6 |
| Application | PAD |
| Resolution | 1366(RGB)×768 , WXGA |
| Composition | Assembly |
| Brightness | 350 cd/m² (Typ.) |
| CR | 800:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | LVDS |
| Panel Brand | AUO |
| Panel Model | B116XAT03.1 |
| Panel Type | a-Si TFT-LCD , Assembly |
| Panel Size | 11.6 inch |
| Active Area | 256.125×144 mm |
| Outline | 288.8×176.8×8.43 mm |
| Surface | Hard coating (8H) |
| Contrast Ratio | 800:1 (Typ.) |
| Display Colors | 16.7M (8-bit), CIE193150% |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Signal Interface | LVDS (1 ch, 8-bit), 40 pins |
| Input Voltage | 3.3V (Typ.) |
| B116XAN01.0 | AUO | 11.6 | 1366×768 |
| B116XAN03.1 HW0A | AUO | 11.6 | 1366×768 |
| B116XAT03.1 | AUO | 11.6 | 1366×768 |
| B116XTB01.0 | AUO | 11.6 | 1366×768 |
| B116XTN02.3 HW0A | AUO | 11.6 | 1366×768 |
| B116XTT01.0 | AUO | 11.6 | 1366×768 |
| B116XTT01.1 | AUO | 11.6 | 1366×768 |
| B116XW01 V0 | AUO | 11.6 | 1366×768 |
| B116XW02 V0 | AUO | 11.6 | 1366×768 |
| B116XW05 V0 | AUO | 11.6 | 1366×768 |
| CLAA080WQ02 XG | CPT | 8.0 | 800×1280 |
| HT10X21-311 | HYDIS | 10.4 | 1024×768 |
| HV070WX2-1E0 | HYDIS | 7.0 | 800×1280 |
| LD089WX1-SL03 | LG Display | 8.9 | 1280×768 |
| LP116WH4-SLA1 | LG Display | 11.6 | 1366×768 |
| LTL101AL06-803 | Samsung | 10.1 | 1280×800 |
| LTL101AL06-W02 | Samsung | 10.1 | 1280×800 |
| LTN121AP06-301 | Samsung | 12.1 | 1280×800 |
| TPF0702001N | JDI | 7.0 | 1200×1920 |
| VVX07F023B00 | Panasonic | 7.0 | 1200×1920 |
