| PartNumber | B133EW04 V0 |
| Brand | AUO |
| Size | 13.3 |
| Application | NBPC |
| Resolution | 1280(RGB)×800 , WXGA |
| Composition | LCM |
| Brightness | 275 cd/m² (Typ.) |
| CR | 600:1 |
| Colors | 262K |
| Backlight | WLED |
| Interface | LVDS |
| Panel Brand | AUO |
| Panel Model | B133EW04 V0 6 Compatible model |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 13.3 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 286.08×178.8 mm |
| Shape Style | Flat (PCBA Flat, Depth 3.4~4.0mm) |
| Surface | Glare (Haze 0%), Hard coating (3H) |
| Contrast Ratio | 600:1 (Typ.) |
| Display Colors | 262K (6-bit), CIE193145% |
| Response Time | 20 (Typ.)(Tr+Td) |
| Viewing Angle | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 9S6PWLEDWithout Driver |
| Signal Interface | LVDS (1 ch, 6-bit), 30 pins |
| Input Voltage | 3.3V (Typ.) |
| B133EW01 V0 | AUO | 13.3 | 1280×800 |
| B133EW01 V3 | AUO | 13.3 | 1280×800 |
| B133EW01 V9 | AUO | 13.3 | 1280×800 |
| B133EW03 V0 | AUO | 13.3 | 1280×800 |
| B133EW03 V1 | AUO | 13.3 | 1280×800 |
| B133EW03 V2 | AUO | 13.3 | 1280×800 |
| B133EW04 V0 | AUO | 13.3 | 1280×800 |
| B133EW04 V4 | AUO | 13.3 | 1280×800 |
| B133EW05 V0 | AUO | 13.3 | 1280×800 |
| B133EW07 V2 | AUO | 13.3 | 1280×800 |
| B121EW09 V3 HW0A | AUO | 12.1 | 1280×800 |
| B141EW04 V3 | AUO | 14.1 | 1280×800 |
| B141PW04 V0 HW1A | AUO | 14.1 | 1440×900 |
| LP129QE1-SPA1 | LG Display | 12.9 | 2560×1700 |
| LP156WF4-SPU1 | LG Display | 15.6 | 1920×1080 |
| LTM11C307 | TOSHIBA | 11.3 | 1024×768 |
| LTN156AT06-001 | Samsung | 15.6 | 1366×768 |
| M140NWR1 R0 | IVO | 14.0 | 1366×768 |
| N121IB-L06 | Innolux | 12.1 | 1280×800 |
| N170C3-L01 | Innolux | 17.0 | 1440×900 |
