PartNumber | B133HAK02.2 |
Brand | AUO |
Size | 13.3 |
Application | Laptop |
Resolution | 1920×1080 |
Composition | a-Si TFT-LCD, LCM |
Brightness | |
CR | 700:1 |
Colors | 16.7M |
Backlight | WLED |
Interface | |
Model | B133HAK02.2 |
Diagonal Size | 13.3 inch |
Type | a-Si TFT-LCD, LCM |
Pixel Format | 1920(RGB)×1080 [FHD] 166PPI |
Configuration | RGB Vertical Stripe |
Active Area | 293.76(H)×165.24(V) mm |
Outline Dim. | - |
Bezel Area | - |
Treatment | Hard coating (3H) |
Luminance | - |
Contrast Ratio | 700:1 (Typ.) (TM) |
View Direction | Symmetry |
Response Time | 25 (Typ.)(Tr+Td) |
Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
Operating Mode | AHVA, Normally Black, Transmissive |
Support Color | 16.7M |
Light Source | WLED , 15K hours , With LED Driver |
Form Style | Slim (PCBA Flat, T≤3.2mm) |
Designed For | Laptop |
Frame Rate | 60Hz |
Touch Panel | On-Cell Touch |
Operating Temperature: -20 ~ 60 °C ; Storage Temperature: -20 ~ 60 °C |
