| PartNumber | B140XTN07.1 |
| Brand | AUO |
| Size | 14.0 |
| Application | Laptop |
| Resolution | 1366×768 |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | |
| CR | 400:1 |
| Colors | 262K |
| Backlight | WLED |
| Interface | |
| Diagonal Size | 14.0 inch |
| Pixel Format | 1366(RGB)×768 [WXGA] 112PPI |
| Active Area | 309.399(H)×173.952(V) mm |
| Bezel Area | - |
| Luminance | 220 cd/m² (Typ.) |
| View Direction | 6 o'clock |
| Viewing Angle | 45/45/15/40 (Typ.)(CR≥10) |
| Support Color | 262K 45% NTSC |
| Form Style | Slim (PCBA Flat, T≤3.2mm) |
| Frame Rate | 60Hz |
| Model | B140XTN07.1 (AUO713C) |
| Type | a-Si TFT-LCD , LCM |
| Configuration | RGB Vertical Stripe |
| Outline Dim. | 315.9(H)×205.1(V) ×3(D) mm |
| Treatment | Antiglare, Hard coating (3H) |
| Contrast Ratio | 400:1 (Typ.) (TM) |
| Response Time | 8 (Typ.)(Tr+Td) |
| Operating Mode | TN, Normally White, Transmissive |
| Light Source | WLED , 15K hours , With LED Driver |
| Designed For | Laptop |
| Touch Panel | Without |
