| PartNumber | B140ZAN01.1 |
| Brand | AUO |
| Size | 14.0 |
| Application | Laptop |
| Resolution | 3840×2160 |
| Composition | LCM , a-Si TFT-LCD |
| Brightness | |
| CR | 1200:1 |
| Colors | 16.7M |
| Backlight | WLED , 15K hours , With LED Driver |
| Interface | |
| Manufacturer | AUO |
| Screen Size | 14.0 inch |
| Pixel Number | 3840(RGB)×2160 (UHD) 315PPI |
| Active Area(mm) | 309.31 × 173.98 (H×V) |
| Luminance | - |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Good View at | Symmetry |
| Color Depth | 16.7M 72% NTSC |
| Outline Shape | Slim (PCBA Flat, T≤3.2mm) |
| Refresh Rate | 60Hz |
| Model Name | B140ZAN01.1 |
| Screen Type | LCM , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Outline(mm) | 315.01 × 199.04 × 2.4 (H×V×D) |
| Contrast Ratio | 1200 : 1 (Typ.) (TM) |
| Work Mode | AHVA, Normally Black, Transmissive |
| Response | 35 (Typ.)(Tr+Td) ms |
| Used for | Laptop |
| Touchscreen | Without |
| B140XW03 V1 | AUO | 14.0 | 1366×768 |
| CLAA140WB11A | CPT | 14.0 | 1366×768 |
| LP140WD2-TLE2 | LG Display | 14.0 | 1600×900 |
| LP140WF1-SPU1 | LG Display | 14.0 | 1920×1080 |
| LP140WH2-TLN1 | LG Display | 14.0 | 1366×768 |
| LTN140AT06-A01 | Samsung | 14.0 | 1366×768 |
| LTN140AT21-B01 | Samsung | 14.0 | 1366×768 |
| LTN140AT22-W01 | Samsung | 14.0 | 1366×768 |
| N140B6-L02 | Innolux | 14.0 | 1366×768 |
| N140FGE-EA2 | Innolux | 14.0 | 1600×900 |
