| PartNumber | B141EW02 V3 |
| Brand | AUO |
| Size | 14.1 |
| Application | NBPC |
| Resolution | 1280(RGB)×800 , WXGA |
| Composition | LCM |
| Brightness | 200 cd/m² (Typ.) |
| CR | 400:1 |
| Colors | 262K |
| Backlight | CCFL |
| Interface | LVDS |
| Panel Brand | AUO |
| Panel Model | B141EW02 V3 1 Compatible model |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 14.1 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 303.36×189.6 mm |
| Outline | 319.5×205.5×5.5 mm |
| Shape Style | Wedge (PCBA Bent, Depth ≥5.2mm) |
| Surface | Glare (Haze 0%), Hard coating (2H) |
| Contrast Ratio | 400:1 (Typ.) |
| Display Colors | 262K (6-bit) |
| Response Time | 15/10 (Typ.)(Tr/Td) |
| Viewing Angle | 45/45/20/35 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 1 pcsCCFLWithout Driver |
| Signal Interface | LVDS (1 ch, 6-bit), 30 pins |
| Input Voltage | 3.3V (Typ.) |
| B141EW02 V3 | AUO | 14.1 | 1280×800 |
| B141EW03 V3 | AUO | 14.1 | 1280×800 |
| B141EW04 V0 | AUO | 14.1 | 1280×800 |
| B141EW04 V3 | AUO | 14.1 | 1280×800 |
| B141EW04 V4 | AUO | 14.1 | 1280×800 |
| B141EW04 V5 | AUO | 14.1 | 1280×800 |
| B141EW04 V7 | AUO | 14.1 | 1280×800 |
| B141EW05 V0 | AUO | 14.1 | 1280×800 |
| B141EW05 V2 | AUO | 14.1 | 1280×800 |
| B141EW05 V5 | AUO | 14.1 | 1280×800 |
| B133HAN02.5 | AUO | 13.3 | 1920×1080 |
| B141XG08 V3 | AUO | 14.1 | 1024×768 |
| LP133WX3-TLA6 | LG Display | 13.3 | 1280×800 |
| LP150E07-TL02 | LG Display | 15.0 | 1400×1050 |
| LP154WU1-A1K1 | LG Display | 15.4 | 1920×1200 |
| LP171WP9-TLB2 | LG Display | 17.1 | 1440×900 |
| LTN154P3-L02 | Samsung | 15.4 | 1680×1050 |
| LTN160AT03-001 | Samsung | 16.0 | 1366×768 |
| LTN173HT02-X01 | Samsung | 17.3 | 1920×1080 |
| N144NGE-E41 | Innolux | 14.4 | 1792×768 |
