| PartNumber | B156XTN08.2 |
| Brand | AUO |
| Size | 15.6 |
| Application | Laptop |
| Resolution | 1366×768 |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | |
| CR | 500:1 |
| Colors | 262K |
| Backlight | WLED |
| Interface | |
| Diagonal Size | 15.6 inch |
| Pixel Format | 1366(RGB)×768 [WXGA] 100PPI |
| Active Area | 344.232(H)×193.536(V) mm |
| Luminance | - |
| View Direction | 6 o'clock |
| Viewing Angle | 45/45/15/35 (Min.)(CR≥10) |
| Support Color | 262K |
| Form Style | Slim (PCBA Bent, T≤3.0mm) |
| Frame Rate | 60Hz |
| Model | B156XTN08.2 |
| Type | a-Si TFT-LCD , LCM |
| Configuration | RGB Vertical Stripe |
| Outline Dim. | - |
| Contrast Ratio | 500:1 (Typ.) (TM) |
| Response Time | 8 (Typ.)(Tr+Td) |
| Operating Mode | TN, Normally White, Transmissive |
| Light Source | WLED , 15K hours , With LED Driver |
| Designed For | Laptop |
| Touch Panel | - |
