| PartNumber | B156ZAN05.1 |
| Brand | AUO |
| Size | 15.6 |
| Application | Laptop |
| Resolution | 3840(RGB)×2160, UHD, 283PPI |
| Composition | LTPS TFT-LCD , LCM |
| Brightness | 400 cd/m² (Typ.) |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | Mini |
| Interface | |
| Panel Brand | AUO |
| Panel Size | 15.6" |
| Display Area | 344.272(W)×193.622(H) mm |
| Outline Size | 350.66(W)×216.45(H) ×2.6(D) mm |
| Viewing Angle | 85/85/85/85 (Max.)(CR≥10) |
| Best View on | Symmetry |
| Display Colors | 16.7M 100% Adobe RGB |
| Frequency | 120Hz |
| Shape Style | Slim (PCBA Flat, T≤3.2mm) |
| Panel Model | B156ZAN05.1 |
| Panel Type | LTPS TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | - |
| Surface | Antiglare |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Display Mode | AHVA, Normally Black, Transmissive |
| Response Time | 8.3 (Typ.)(G to G) |
| Lamp Type | Mini LED , 15K hours , With LED Driver |
| Touch Screen | Without |
