| PartNumber | BP082WX1-100 |
| Brand | BOE |
| Size | 8.2 |
| Application | PAD |
| Resolution | 1280(RGB)×800 , WXGA |
| Composition | LCM |
| Brightness | 450 cd/m² (Typ.) |
| CR | 800:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | LVDS |
| Panel Brand | BOE |
| Panel Model | BP082WX1-100 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 8.2 inch |
| Display Mode | ADS, Normally Black, Transmissive |
| Active Area | 176.64×110.4 mm |
| Outline | 187.84×122.3 mm |
| Surface | Hard coating (3H), Antireflection |
| Contrast Ratio | 800:1 (Typ.) |
| Display Colors | 16.7M (6-bit + Hi-FRC), CIE193150% |
| Response Time | 24 (Typ.)(Tr+Td) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 3 stringsWLEDWithout Driver |
| Signal Interface | LVDS (1 ch, 8-bit), 40 pins |
| Input Voltage | 3.3V (Typ.) |
