| PartNumber | C080EAN04.1 |
| Brand | AUO |
| Size | 8.0 |
| Application | Automotive Display |
| Resolution | 1280×720 |
| Composition | LCM, a-Si TFT-LCD |
| Brightness | |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | 6S4P WLED , 30K hours , No Driver |
| Interface | |
| Manufacturer | AUO |
| Model Name | C080EAN04.1 |
| Screen Size | 8.0 inch |
| Screen Type | LCM, a-Si TFT-LCD |
| Pixel Number | 1280(RGB)×720 (WXGA) 184PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 176.64 × 99.36 (H×V) |
| Outline(mm) | 186.5 × 117.12 (H×V×D) |
| Bezel Area(mm) | 179.55 × 105.36 (H×V) |
| Treatment | Antiglare |
| Luminance | 750 cd/m² (Typ.) |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
| Response | 20 (Max.)(Tr+Tf) ms |
| Good View at | Symmetry |
| Work Mode | AHVA, Normally Black, Transmissive |
| Color Depth | 16.7M 68% NTSC |
| Mass | 229±23g |
| Used for | Automotive Display |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
