| PartNumber | C084SAT01.1 |
| Brand | AUO |
| Size | 8.4 |
| Application | Automotive Display |
| Resolution | 800×600 |
| Composition | LCM , a-Si TFT-LCD |
| Brightness | |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | WLED , No Driver |
| Interface | |
| Manufacturer | AUO |
| Screen Size | 8.4 inch |
| Pixel Number | 800×600(RGB) (SVGA) 118PPI |
| Active Area(mm) | 170.88 × 128.16 (H×V) |
| Luminance | - |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
| Good View at | Symmetry |
| Color Depth | 16.7M |
| Mass | - |
| Refresh Rate | 60Hz |
| Max. Ratings | Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 90 °C |
| Model Name | C084SAT01.1 |
| Screen Type | LCM , a-Si TFT-LCD |
| Arrangement | RGB Horizontal Stripe |
| Outline(mm) | - |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Response | 15/20 (Typ.)(Tr/Td) ms |
| Work Mode | AHVA, Normally Black, Transmissive |
| Used for | Automotive Display |
| Touchscreen | Without |
