| PartNumber | C090EAN01.0 |
| Brand | AUO |
| Size | 9.0 |
| Application | Automotive Display |
| Resolution | 1280×720 |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | LVDS |
| Model | C090EAN01.0 |
| Diagonal Size | 9.0 inch |
| Type | a-Si TFT-LCD, LCM |
| Pixel Format | 1280(RGB)×720 [WXGA] 163PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 198.72(H)×111.78(V) mm |
| Outline Dim. | - |
| Luminance | - |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 15/15 (Max.)(Tr/Td) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
| Operating Mode | AHVA, Normally Black, Transmissive |
| Support Color | 16.7M 70% NTSC |
| Light Source | WLED |
| Weight | - |
| Designed For | Automotive Display |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Interface Type | LVDS (1 ch, 8-bit) |
| Environment | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C ; Vibration Level: 2.9G (28.4 m/s²) |
