| PartNumber | C101EAN01.1 |
| Brand | AUO |
| Size | 10.1 |
| Application | Automotive Display |
| Resolution | 1280(RGB)×720, WXGA, 145PPI |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | - |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | |
| Panel Brand | AUO |
| Panel Model | C101EAN01.1 |
| Panel Size | 10.1" |
| Panel Type | a-Si TFT-LCD, LCM |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 223.68(W)×125.82(H) mm |
| Bezel Opening | - |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
| Display Mode | AHVA, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 20/20 (Max.)(Tr/Td) |
| Display Colors | 16.7M |
| Lamp Type | WLED |
| Frequency | 60Hz |
| Touch Screen | Without |
| Panel Weight | - |
| Environment | Operating Temp.: -30 ~ 85 °C ; Storage Temp.: -40 ~ 95 °C ; Vibration Level: 2.9G (28.4 m/s²) |
