| PartNumber | C123HAN02.5 |
| Brand | AUO |
| Size | 12.3 |
| Application | Automotive Display |
| Resolution | 1920×720 |
| Composition | LCM, a-Si TFT-LCD |
| Brightness | |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | 8S4P WLED , 10K hours , No Driver |
| Interface | |
| Manufacturer | AUO |
| Model Name | C123HAN02.5 |
| Screen Size | 12.3 inch |
| Screen Type | LCM, a-Si TFT-LCD |
| Pixel Number | 1920(RGB)×720 167PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 292.032 × 109.512 (H×V) |
| Outline(mm) | 310.75 × 129.86 × 16.23 (H×V×D) |
| Bezel Area(mm) | 293.94 × 111.42 (H×V) |
| Treatment | Antiglare |
| Luminance | 600 cd/m² (Min.) |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
| Response | 15/45 (Typ.)(Tr/Td) ms |
| Good View at | Symmetry |
| Work Mode | AHVA, Normally Black, Transmissive |
| Color Depth | 16.7M 75% NTSC |
| Mass | 570±57g |
| Used for | Automotive Display |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
