| PartNumber | CC495PU1L |
| Brand | PANDA |
| Size | 50 |
| Application | TV Sets |
| Resolution | 3840×2160 |
| Composition | CELL , Oxide TFT-L |
| Brightness | |
| CR | 5000:1 |
| Colors | 1.07B |
| Backlight | No B/L |
| Interface | V-by-One |
| Manufacturer | PANDA |
| Model Name | CC495PU1L |
| Screen Size | 50 inch |
| Screen Type | CELL , Oxide TFT-LCD |
| Pixel Number | 3840(RGB)×2160 (UHD) 89PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 1095.84 × 616.41 (H×V) |
| Outline(mm) | 1106.8 × 628.01 × 1.37 (H×V×D) |
| Bezel Area(mm) | - |
| Treatment | Antiglare, Hard coating (2H) |
| Luminance | 0 cd/m² |
| Contrast Ratio | 5000 : 1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Response | 8 (Typ.)(G to G) ms |
| Good View at | Symmetry |
| Work Mode | ASV, Normally Black, Transmissive |
| Glass Thickness | 0.50+0.50 mm |
| Transmissivity | 5.5% (Typ.)(with Polarizer) |
| Color Depth | 1.07B 72% NTSC |
| Mass | 2.06Kgs (Typ.) |
| Used for | TV Sets |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Driver IC list | Built-in COF 12 source + 12 gate chips |
| Signal Type | V-by-One 8 lane , 51 pins Connector |
| Voltage Supply | 12.0V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| LC500DUE-VGM1 | LG Display | 50 | 1920×1080 |
| T500HVD01.0 | AUO | 50 | 1920×1080 |
| T500HVN04.1 CELL | AUO | 50 | 1920×1080 |
| T500HVN05.0 CELL | AUO | 50 | 1920×1080 |
| T500HVN07.5 CELL | AUO | 50 | 1920×1080 |
| V500DJ2-KS5 | Innolux | 50 | 3840×2160 |
| V500DK1-KS5 | Innolux | 50 | 3840×2160 |
| V500HJ1-LE2 | Innolux | 50 | 1920×1080 |
| V500HJ1-PE6 | Innolux | 50 | 1920×1080 |
| V500HK1-PS6 | Innolux | 50 | 1920×1080 |
