| PartNumber | CC500PV6D |
| Brand | PANDA |
| Size | 50 |
| Application | TV Sets |
| Resolution | 3840(RGB)×2160, UHD, 89PPI |
| Composition | Oxide TFT-LCD, CELL |
| Brightness | 0 cd/m² |
| CR | 6000:1 |
| Colors | 1.07B |
| Backlight | No |
| Interface | USI-T |
| Panel Brand | PANDA |
| Panel Model | CC500PV6D |
| Panel Size | 50" |
| Panel Type | Oxide TFT-LCD, CELL |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 1095.8(W)×616.41(H) mm |
| Bezel Opening | - |
| Outline Size | 1105.84(W)×627.91(H) ×1.37(D) mm |
| Surface | Antiglare (Haze 2.3%), Hard coating (3H) |
| Contrast Ratio | 6000:1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Display Mode | UV2A, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 8 (Typ.)(G to G) |
| Glass Depth | 0.50+0.50 mm |
| Transmissivity | 5.0% (Typ.)(with Polarizer) |
| Display Colors | 1.07B 70% NTSC |
| Lamp Type | No B/L |
| Frequency | 60Hz |
| Touch Screen | Without |
| Driver IC | COF Built-in 12 source chips |
| Panel Weight | 2.15Kgs (Typ.) |
| Signal Interface | USI-T , 96 pins Connector |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 65 °C |
