| PartNumber | CLAA042JD02 XN |
| Brand | CPT |
| Size | 4.2 |
| Application | Automotive Display |
| Resolution | 480×272 |
| Composition | LCM , a-Si TFT-LCD |
| Brightness | |
| CR | 1000:1 |
| Colors | 262K |
| Backlight | WLED , 50K hours , No Driver |
| Interface | |
| Manufacturer | CPT |
| Screen Size | 4.2 inch |
| Pixel Number | 480(RGB)×272 (WQVGA) 131PPI |
| Active Area(mm) | 92.88 × 52.632 (H×V) |
| Bezel Area(mm) | 94.48 × 54.27 (H×V) |
| Luminance | 700 (Typ.)(cd/m²) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Good View at | Symmetry |
| Color Depth | 262K |
| Mass | 97.4g (Max.) |
| Refresh Rate | 60Hz |
| Model Name | CLAA042JD02 XN |
| Screen Type | LCM , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Outline(mm) | 102.5 × 67 × 11.3 (H×V×D) |
| Treatment | Antiglare |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Work Mode | HFFS, Normally Black, Transmissive |
| Response | 25 (Max.)(Tr+Td) ms |
| Used for | Automotive Display |
| Touchscreen | Without |
