| PartNumber | CLAA069LA0HCW |
| Brand | CPT |
| Size | 7.0 |
| Application | Automotive Display |
| Resolution | 800(RGB)×480, WVGA, 134PPI |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | |
| CR | |
| Colors | 262K |
| Backlight | WLED |
| Interface | |
| Panel Brand | CPT |
| Panel Size | 7.0" |
| Display Area | 156.6(W)×81.6(H) mm |
| Viewing Angle | 75/75/60/70 (Typ.)(CR≥10) |
| Best View on | 6 o'clock |
| Display Colors | 262K 70% NTSC |
| Frequency | 60Hz |
| Weight | 165g (Typ.) |
| Panel Model | CLAA069LA0HCW |
| Panel Type | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | - |
| Display Mode | TN, Normally White, Transmissive |
| Response Time | 20 (Typ.)(Tr+Td) |
| Lamp Type | WLED |
| Touch Screen | Without |
| CLAA061LA0ACW | CPT | 6.1 | 800×480 |
| CLAA061LA0BCW | CPT | 6.1 | 800×480 |
| CLAA069LA0ACW | CPT | 7.0 | 800×480 |
| CLAA069LA0FCW | CPT | 7.0 | 800×480 |
| CLAA069LA0NCW | CPT | 7.0 | 800×480 |
| CLAA069LA1AAW | CPT | 7.0 | 800×480 |
| CLAA069LB02CW | CPT | 7.0 | 800×480 |
| CLAA069LB03CW | CPT | 7.0 | 800×480 |
| CLAA069LB06 CW | CPT | 7.0 | 800×480 |
| CLAA069LC01XW | CPT | 7.0 | 800×480 |
