| PartNumber | CLAA101WK07 XN |
| Brand | CPT |
| Size | 10.1 |
| Application | Automotive Display |
| Resolution | 1280×720 |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | |
| CR | 900:1 |
| Colors | 262K/16.7M |
| Backlight | WLED |
| Interface | |
| Diagonal Size | 10.1 inch |
| Pixel Format | 1280(RGB)×720 [WXGA] 144PPI |
| Active Area | 224.64(H)×126.36(V) mm |
| Bezel Area | 227.64(H)×129.36(V) mm |
| Luminance | 600 cd/m² (Typ.) |
| View Direction | Symmetry |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Support Color | 262K/16.7M 70% NTSC |
| Weight | 430g (Typ.) |
| Frame Rate | 60Hz |
| Model | CLAA101WK07 XN |
| Type | a-Si TFT-LCD , LCM |
| Configuration | RGB Vertical Stripe |
| Outline Dim. | 238.8(H)×148.05(V) ×8.7(D) mm |
| Treatment | Antiglare (Haze 25%), Hard coating (3H) |
| Contrast Ratio | 900:1 (Typ.) (TM) |
| Response Time | 25 (Typ.)(Tr+Td) |
| Operating Mode | HFFS, Normally Black, Transmissive |
| Light Source | WLED [6S5P] , 30K hours , W/O Driver |
| Designed For | Automotive Display |
| Touch Panel | Without |
