| PartNumber | CLAA123PA02CW |
| Brand | CPT |
| Size | 12.3 |
| Application | Industrial Outdoor H |
| Resolution | 1440×540 |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | |
| CR | 700:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | LVDS |
| Model | CLAA123PA02CW |
| Diagonal Size | 12.3 inch |
| Type | a-Si TFT-LCD, LCM |
| Pixel Format | 1440(RGB)×540 125PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 291.6(H)×109.35(V) mm |
| Outline Dim. | 312.9(H)×132.2(V) ×19.2(D) mm |
| Bezel Area | 294.8(H)×112.4(V) mm |
| Treatment | Antiglare (Haze 25%) |
| Luminance | 800 cd/m² (Typ.) |
| Contrast Ratio | 700:1 (Typ.) (TM) |
| View Direction | 6 o'clock |
| Response Time | 25 (Typ.)(Tr+Td) |
| Viewing Angle | 60/60/50/60 (Typ.)(CR≥10) |
| Operating Mode | TN, Normally White, Transmissive |
| Support Color | 16.7M 70% NTSC |
| Light Source | WLED [8S3P] , 30K hours , W/O Driver |
| Weight | 510g (Typ.) |
| Designed For | Industrial Outdoor High Brightness Automotive Display |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Interface Type | LVDS (1 ch, 8-bit) , 30 pins Connector |
| Power Supply | 3.3V (Typ.) |
| Environment | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C ; Vibration Level: 2.9G (28.4 m/s²) |
