| PartNumber | CM546B2-001 |
| Brand | CSOT |
| Size | 5.5 |
| Application | Mobile Phone |
| Resolution | 1080(RGB)×1920, FHD, 403PPI |
| Composition | LTPS TFT-LCD, CELL |
| Brightness | 0 cd/m² |
| CR | 1500:1 |
| Colors | 16.7M |
| Backlight | No |
| Interface | |
| Panel Brand | CSOT |
| Panel Model | CM546B2-001 |
| Panel Size | 5.5" |
| Panel Type | LTPS TFT-LCD, CELL |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 68.04(W)×120.96(H) mm |
| Bezel Opening | - |
| Outline Size | 69.44(W)×126.81(H) ×0.45(D) mm |
| Surface | With Polarizer |
| Contrast Ratio | 1500:1 (Typ.) (TM) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
| Display Mode | FFS, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 35 (Typ.)(Tr+Td) |
| Glass Depth | 0.15+0.15 mm |
| Transmissivity | 4.69% (Typ.)(with APCF) |
| Display Colors | 16.7M 80% NTSC |
| Lamp Type | No B/L |
| Frequency | - |
| Touch Screen | In-Cell Touch |
| Driver IC | COG Built-in TD4310 |
| Panel Weight | TBD |
| Environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| CM546B1-002 | CSOT | 5.5 | 1080×1920 |
| E555HBM2 | EDO | 5.5 | 720×1280 |
| LH550WF1-SD01 | LG Display | 5.5 | 1080×1920 |
| LM6Q35 | SHARP | 5.5 | 320×240 |
| LS055R1SC01 | SHARP | 5.5 | 1440×2560 |
| NL3224AC35-01 | NLT | 5.5 | 320×240 |
| NL3224AC35-10 | NLT | 5.5 | 320×240 |
| NL3224BC35-20 | NLT | 5.5 | 320×240 |
| NL3224BC35-22 | NLT | 5.5 | 320×240 |
| TM055JDHP71 | Tianma | 5.5 | 720×1280 |
